High Temperature Filter

Amorair high-temp filter uses durable, heat-resistant fiberglass as filter material, the special high-temperature resistant silica gel or ceramic adhesive is used to fix and seal the filter elements inside the metal frame.  These filters are crucial for various applications where standard filters would degrade or fail due to heat，and mainly used in ultra-clean ovens and other equipment and systems that require high-temperature air purification.

Applications:

>> High-temperature sterilization tunnels and cleanroom ovens in the pharmaceutical industry require high-temperature air purification devices and systems.

>> High-temperature air purification devices and systems in the chemical and food and beverage industries.

>> Paint shops in automotive factories.

>> Ventilation systems with strict fire protection requirements or high ventilation temperatures.

   Frame Material                          Aluminum / Galvanized Steel / Stainless Steel

   Media                                         Moisture-resistant Fiberglass

   U.S. Efficiency                          MERV 11, MERV 13, MERV 14, MERV15, 99.95%@ MPPS, 99.995%@ MPPS

   Euro Efficiency                         M6, F7, F8, F9, H13, H14

   Max Temperature                      250 °C (482 °F)

   Separator                                   Aluminum Foil

   Header                                       No Header /Single Header /Double Header

   Sealant                                       High Temperature Resistant Sealant

   Gasket                                        High Temperature Resistant Gasket

   Depth                                          80mm (3.1″) /150mm (5.9″) /220mm (8.7″) /292mm (11.5″)
